Smart3d MiiCraft+HR 3D printer
Descrizione
| Printing Function | Build Size | 43mm x 27mm x 180mm |
| XY resolution | 56 microns | |
| Z-axis resolution | A . 5 microns as a step from 5~200 microns | |
| Speed | 3cm/hour* @ 100microns/z axis
2cm/hour* @ 40microns/z axis 1cm/hour* @ 25microns/z axis *material dependant |
|
| Hardware | Product Architecture I | Industrial Equipment (standalone, no need to connect to a PC when printing) |
| Product Architecture II | Printing and post curing at the same time | |
| Software | Printing Software | Smart3d software for Rhino 5.0 (tuned for MiiCraft) |
| Smart3d SupportGenerator (Automatic support generation) | ||
| Auto Model repairing | ||
| Smart3d SAMURAI Model Slicer | ||
| Printing Parameter Setting | ||
| Printer Control Software | MiiCraft+ control User Interface- via browser | |
| Printing Progress Overview | ||
| Accessory | Smart3d Anti-stick film x 6 | |
| Picker x 2 | ||
| RJ45 Cable | ||
| Resin x 1 (150g/bottle) | ||
| Power adapter+ power cord | ||
| Dimension & Weight | Printer | 20.8cm(L) x 20.5cm(W) x 33.5cm(H) , 8.5Kg |
| Full package | 41.5cm(L) x 39.0cm(W) x 45.0cm(H), 10Kg | |
